Maximize Your Turf’s Potential with the Verti-Drain® 7626 from Redexim
The Verti-Drain® 7626 by Redexim is ideal for large-scale applications including sports fields, golf courses and municipal grounds. This advanced aerator works up to a depth of 16 inches (400 mm), offering powerful aeration for optimal turf health and resilience.
Penetrates up to 16 inches, fostering deep root growth, enhanced water penetration, and improved nutrient uptake, ensuring robust and stress-resistant turf.
With a wide working width of 2.6 meters, the 7626 efficiently covers large areas, reducing the time and effort needed for aeration tasks.
Compatible with a variety of solid and hollow tines, the Verti-Drain® 7626 adapts to different soil conditions, delivering tailored aeration for diverse applications.
Constructed with a heavy-duty chassis and durable components, the 7626 is built to withstand challenging conditions, offering long-lasting reliability and performance.
The Verti-Drain® 7626 has a three-point hitch and integrated parking stands for easy setup and operation. Its intuitive controls and straightforward design make it accessible for operators of all skill levels, enhancing productivity and reducing downtime.
Optional components, such as the rear roller kit and core collector, ensure a smooth and professional finish post-aeration, maintaining the pristine look of high-visibility areas.
| SKU | 7626 |
| Operation | Tractor Mounted |
| Working width (m) | 2.6 |
| Working width (inch) | 102 |
| Max. Working depth (mm) | 400 |
| Max. Working depth (inch) | 16 |
| Working speed at hole spacing 65 mm (km h) | 0.75 |
| Working speed at hole spacing 2 1 2 inch (mph) | 0.47 |
| Weight (kg) | 2010 |
| Weight (lbs) | 4431 |
| Hole distance with 12 mm tines (mm) | 65 |
| Hole distance with 1 2 x 6 inch tines (inch) | 2.5 |
| Hole distance with 24 mm tines (mm) | 129 |
| Hole distance with 1 x 16 inch tines (inch) | 5 |
| Hole spacing distance driving direction (mm) | 50-195 |
| Hole spacing distance driving direction (inch) | 2 – 7-1/2 |
| Max. Diameter solid tine (mm) | 24 x 400 |
| Max. Diameter solid tine (inch) | 1 x 16 |
| Max. Diameter hollow tine (mm) | 32 x 300 |
| Max. Diameter hollow tine (inch) | 1-1/4 x 12 |
| Min. Tractor HP required | 65 |
| Min. Lifting capacity 610 mm behind the lifting eyes (kg) | 2300 |
| Min. Lifting capacity 24 inch behind the lifting eyes (lbs) | 5070 |
| Max. capacity with spacing 65 mm (m² hr) | 1950 |
| Max. capacity with spacing 2 1 2 inch (ft² hr) | 20989 |
| Three-point hitch | 3-point CAT 2 |
| Rpm Max. | 500 |
| Gear case oil | 80W90 – 6.5 |
| Lubricant | EP2 |
| Slip clutch setting | 1100 Nm |
| Description | Quantity | Article number |
|---|---|---|
| Toolbox with combi tool and manual | 1 | |
| PTO Shaft | 1 | |
| Solid Tine 24×400 | 20 | 2382640 |
| Description | Quantity | Article number |
|---|---|---|
| Turf Hold Down Kit for 12mm tines – 7626 | 1 | 211.762.002 |
| Turf Hold Down Kit for 24mm tines – 7626 | 1 | 211.762.004 |
| Anti-vibration sytem 76 serie | 1 | 211.700.502 |
| Wheel Kit for 7626 | 1 | 211.762.006 |
| Rotating Brush for 7526 / 7626 | 1 | 211.762.106 |
| Solid Tine 5×125 | 40 | 311.105.125 |
| Requires | ||
| Adapter 5mm tines (3/16″) | 40 | 314.205.043 |
| Solid Tine 8×150 | 40 | 311.108.150 |
| Requires | ||
| Adapter 8mm tines (5/16″) | 40 | 314.208.043 |
| Solid Tine 8×150 | 80 | 311.108.150 |
| Requires | ||
| MTH Block for (8) tines 8mm (5/16″) | 10 | 9990211 |
| Solid Tine 8×175 | 40 | 9990056 |
| Requires | ||
| Adapter 8mm tines (5/16″) | 40 | 314.208.043 |
| Solid Tine 8×175 | 80 | 9990056 |
| Requires | ||
| MTH Block for (8) tines 8mm (5/16″) | 10 | 9990211 |
| Solid Tine 8×250 | 40 | 9990059 |
| Requires | ||
| Adapter 8mm tines (5/16″) | 40 | 314.208.043 |
| Solid Tine 12×150 | 40 | 311.112.150 |
| Solid Tine 12×200 | 40 | 311.112.200 |
| Solid Tine 12×250 | 40 | 2381837 |
| Solid Tine 12×300 | 40 | 2381838 |
| Solid Tine 18×200 | 20 | 311.118.200 |
| Requires | ||
| Adapter 18mm tines (3/4″) | 20 | 2451800 |
| Solid Tine 18×250 | 20 | 2381841 |
| Requires | ||
| Adapter 18mm tines (3/4″) | 20 | 2451800 |
| Solid Tine 18×300 | 20 | 2382638 |
| Requires | ||
| Adapter 18mm tines (3/4″) | 20 | 2451800 |
| Solid Tine 18×350 | 20 | 311.118.350 |
| Requires | ||
| Adapter 18mm tines (3/4″) | 20 | 2451800 |
| Solid Tine 18×400 | 20 | 2382639 |
| Requires | ||
| Adapter 18mm tines (3/4″) | 20 | 2451800 |
| Solid Tine 24×225 | 20 | 311.124.225 |
| Solid Tine 24×350 | 20 | 311.124.350 |
| Hollow Tine 10×80 (8 shank) | 40 | 311.210.080 |
| Requires | ||
| Adapter 8mm tines (5/16″) | 40 | 314.208.043 |
| Hollow Tine 10×80 (8 shank) | 80 | 311.210.080 |
| Requires | ||
| MTH Block for (8) tines 8mm (5/16″) | 10 | 9990211 |
| Hollow Tine 10×125 (8 shank) | 40 | 311.210.127 |
| Requires | ||
| Adapter 8mm tines (5/16″) | 40 | 314.208.043 |
| Hollow Tine 10×125 (8 shank) | 80 | 311.210.127 |
| Requires | ||
| MTH Block for (8) tines 8mm (5/16″) | 8 | 9990211 |
| Hollow Tine 16×150 (12 shank) | 40 | 311.216.150 |
| Hollow Tine 16×175 (12 shank) | 40 | 9990022 |
| Hollow Tine 19×150 (12 shank) | 40 | 311.219.150 |
| Hollow Tine 19×200(18 shank) | 20 | 311.219.200 |
| Requires | ||
| Adapter 18mm tines (3/4″) | 20 | 2451800 |
| Hollow Tine 19×200 (12 shank) | 40 | 311.219.201 |
| Hollow Tine 19×225 (18 shank) | 20 | 311.219.225 |
| Requires | ||
| Adapter 18mm tines (3/4″) | 20 | 2451800 |
| Hollow Tine 19×225 (12 shank) | 40 | 311.219.226 |
| Hollow Tine 19×250 (12 shank) | 40 | 9990040 |
| Hollow Tine 19×250 (18 shank) | 20 | 9990023 |
| Requires | ||
| Adapter 18mm tines (3/4″) | 20 | 2451800 |
| Hollow Tine 25×200 (18 shank) | 20 | 311.225.200 |
| Requires | ||
| Adapter 18mm tines (3/4″) | 20 | 2451800 |
| Hollow Tine 25×225 (18 shank) | 20 | 311.225.225 |
| Requires | ||
| Adapter 18mm tines (3/4″) | 20 | 2451800 |
| Hollow Tine 25×250 (18 shank) | 20 | 9990024 |
| Requires | ||
| Adapter 18mm tines (3/4″) | 20 | 2451800 |
| Hollow Tine 29×250 (18 shank) | 20 | 9990066 |
| Requires | ||
| Adapter 18mm tines (3/4″) | 20 | 2451800 |
| Hollow Tine 32x21x300mm (1 1/4×13/16×12)”) MD: 24mm | 20 | 9990034 |
| Hollow Tine 32×300 (18 shank) | 20 | 9990041 |
| Requires | ||
| Adapter 18mm tines (3/4″) | 20 | 2451800 |
| Cross Tine 12×90 (8 shank) | 40 | 9990020 |
| Requires | ||
| Adapter 8mm tines (5/16″) | 40 | 314.208.043 |
| Cross Tine 12×90 (8 shank) | 80 | 9990020 |
| Requires | ||
| MTH Block for (8) tines 8mm (5/16″) | 10 | 9990211 |
| Cross Tine 12×90 (12 shank) | 40 | 311.812.090 |
| Cross Tine 19×120 (12 shank) | 40 | 9990021 |
| Chisel Tine 4.8x19x175 (12 shank) | 40 | 311.619.175 |
| Chisel Tine 4.8x19x120 (12 shank) | 40 | 311.619.120 |
* This product may not be available for your region.
