Transform Your Turf with the Verti-Drain® 7316 from Redexim
The Verti-Drain® 7316 by Redexim meets the diverse needs of varying types of turf, from sports fields and golf courses to municipal grounds. This machine is built to handle tough conditions to deliver a high level of performance and efficiency.
Key factors that determine your turf quality include deep root growth, good water filtration and high nutrient uptake. Using the Verti-Drain® 7316, which penetrates soil up to 12 inches (300 mm), enhances all of these and help maintain a healthy turf that can withstand heavy use.
Equipped with a three-speed gearbox, the Verti-Drain® 7316 allows operators to adjust the working speed to match specific conditions, ensuring a perfect finish every time. This flexibility maximizes your productivity and ensures high-quality results, regardless of the task at hand.
Because the Verti-Drain® 7316 can be used on a wide range of turf types, it is important that it also supports a wide range of tine options. You are able to use both solid and hollow tines with the Verti-Drain® 7316, which enables you to tailor the aeration process to your specific needs. Being able to create a custom aeration process allows you to deliver optimal results every time.
Constructed with heavy-duty materials, the Verti-Drain® 7316 is built to withstand continual rigorous use. Its robust design ensures consistent results for years to come, making it a valuable investment for any turf maintenance professional.
The Verti-Drain® 7316 features a three-point hitch and integrated parking stands for straightforward setup and operation. The intuitive controls make it accessible for operators of all skill levels, reducing overall downtime and increasing efficiency.
| SKU | 7316 |
|---|---|
| Working width (m) | 1.6 |
| Working width (inch) | 63 |
| Max. Working depth (mm) | 300 |
| Max. Working depth (inch) | 12 |
| Working speed at hole spacing 65 mm (km h) | 0.85 |
| Working speed at hole spacing 2 1 2 inch (mph) | 0.55 |
| Weight (kg) | 670 |
| Weight (lbs) | 1480 |
| Hole distance with 12 mm tines (mm) | 65 |
| Hole distance with 1 2 x 6 inch tines (inch) | 2.5 |
| Hole distance with 18 mm tines (mm) | 130 |
| Hole distance with 3 4 x 9 inch tines (inch) | 5 |
| Hole spacing distance driving direction (mm) | 25 – 195 |
| Hole spacing distance driving direction (inch) | 1 – 7-1/2 |
| Max. Diameter solid tine (mm) | 18 x 300 |
| Max. Diameter solid tine (inch) | 3/4 x 12 |
| Max. Diameter hollow tine (mm) | 25 x 250 |
| Max. Diameter hollow tine (inch) | 1 x 10 |
| Min. Tractor HP required | 35 |
| Min. Lifting capacity 610 mm behind the lifting eyes (kg) | 1050 |
| Min. Lifting capacity 24 inch behind the lifting eyes (lbs) | 2310 |
| Max. capacity with spacing 65 mm (m² hr) | 1360 |
| Max. capacity with spacing 2 1 2 inch (ft² hr) | 12300 |
| Three-point hitch | 3-point CAT 1 |
| Rpm Max. | 500 |
| Gear case oil | 80W90 – 5 |
| Lubricant | EP 2 |
| Slip clutch setting | 500 Nm |
| Description | Quantity | Article number |
|---|---|---|
| Toolbox with combi tool and manual | 1 | |
| PTO Shaft | 1 | |
| Solid Tine 12×300 | 24 | 2381838 |
| Description | Quantity | Article number |
|---|---|---|
| Turf Hold Down Kit for 12mm tines – 7316 | 1 | 211.731.006 |
| Turf Hold Down Kit for 18mm tines – 7316 | 1 | 211.731.008 |
| Windrow Kit for 71/73/74/75 Series | 1 | 211.731.010 |
| Core Collector for 7316/7416/7516 | 1 | 9200080 |
| Wheel Kit for 73 Series | 1 | 9200100 |
| Rotating Brush for 73 Series | 1 | 211.731.600 |
| Solid Tine 5×125 | 24 | 311.105.125 |
| Requires | ||
| Adapter 5mm tines (3/16″) | 24 | 314.205.043 |
| Solid Tine 5×125 | 144 | 311.105.125 |
| Requires | ||
| MTH Block for (21) tines 5mm (3/16″) | 6 | 9990214 |
| Solid Tine 8×150 | 24 | 311.108.150 |
| Requires | ||
| Adapter 8mm tines (5/16″) | 24 | 314.208.043 |
| Solid Tine 8×150 | 48 | 311.108.150 |
| Requires | ||
| MTH Block for (8) tines 8mm (5/16″) | 6 | 9990208 |
| Solid Tine 8×175 | 24 | 9990056 |
| Requires | ||
| Adapter 8mm tines (5/16″) | 24 | 314.208.043 |
| Solid Tine 8×175 | 48 | 9990056 |
| Requires | ||
| MTH Block for (8) tines 8mm (5/16″) | 6 | 9990208 |
| Solid Tine 8×250 | 24 | 9990059 |
| Requires | ||
| Adapter 8mm tines (5/16″) | 24 | 314.208.043 |
| Solid Tine 12×150 | 24 | 311.112.150 |
| Solid Tine 12×200 | 24 | 311.112.200 |
| Solid Tine 12×250 | 24 | 2381837 |
| Solid Tine 18×200 | 12 | 311.118.200 |
| Solid Tine 18×250 | 12 | 2381841 |
| Solid Tine 18×300 | 12 | 2382638 |
| Hollow Tine 10×80 (8 shank) | 24 | 311.210.080 |
| Requires | ||
| Adapter 8mm tines (5/16″) | 24 | 314.208.043 |
| Hollow Tine 10×80 (8 shank) | 48 | 311.210.080 |
| Requires | ||
| MTH Block for (8) tines 8mm (5/16″) | 6 | 9990208 |
| Hollow Tine 10×125 (8 shank) | 24 | 311.210.127 |
| Requires | ||
| Adapter 8mm tines (5/16″) | 24 | 314.208.043 |
| Hollow Tine 10×125 (8 shank) | 48 | 311.210.127 |
| Requires | ||
| MTH Block for (8) tines 8mm (5/16″) | 6 | 9990208 |
| Hollow Tine 16×150 (12 shank) | 24 | 311.216.150 |
| Hollow Tine 16×175 (12 shank) | 24 | 9990022 |
| Hollow Tine 19×150 (12 shank) | 24 | 311.219.150 |
| Hollow Tine 19×200(18 shank) | 12 | 311.219.200 |
| Hollow Tine 19×200 (12 shank) | 24 | 311.219.201 |
| Hollow Tine 19×225 (18 shank) | 12 | 311.219.225 |
| Hollow Tine 19×225 (12 shank) | 24 | 311.219.226 |
| Hollow Tine 25×200 (18 shank) | 12 | 311.225.200 |
| Hollow Tine 19×250 (18 shank) | 12 | 9990023 |
| Hollow Tine 19×250 (12 shank) | 24 | 9990040 |
| Hollow Tine 25×225 (18 shank) | 12 | 311.225.225 |
| Hollow Tine 25×250 (18 shank) | 12 | 9990024 |
| Cross Tine 12×90 (8 shank) | 24 | 9990020 |
| Requires | ||
| Adapter 8mm tines (5/16″) | 24 | 314.208.043 |
| Cross Tine 12×90 (8 shank) | 48 | 9990020 |
| Requires | ||
| MTH Block for (8) tines 8mm (5/16″) | 6 | 9990208 |
| Cross Tine 12×90 (12 shank) | 24 | 311.812.090 |
| Cross Tine 19×120 (12 shank) | 24 | 9990021 |
| Chisel Tine 4.8x19x175 (12 shank) | 24 | 311.619.175 |
| Chisel Tine 4.8x19x120 (12 shank) | 24 | 311.619.120 |
* This product may not be available for your region.
